Mains choke series (passive)
Current range up to 10 A
With a current range up to 10 A and a wide selection of inductance values, this series covers the range of common device applications.
These components can be integrated quickly and easily thanks to their compliance with the relevant standards for chokes, DIN EN 61558-2-20 and DIN EN 62041, as well as compliance with the glow wire requirements of all materials used in accordance with DIN EN 60335-1 and the use of insulation systems of insulation class B and F in accordance with UL 1446.
max. 4.7 A
EI38
Mains chokes (passive PFC)Inductance 1.0 - 15.0 mH
Rated current: max. 4.7 A
Request product Download product information- Excellent thermal shock behavior
- For standard version with potting box "O":
Self-extinguishing potting and cover material - Maximum safety and durability
- High dielectric strength compared to core
- 100 % routine testing
- RoHS/REACH compliant
Further certifications/approvals on request!
max. 5.2 A
EI30
Mains chokes (passive PFC)Inductance 1.0 - 20.0 mH
Rated current: max. 5.2 A
Request product Download product information- Excellent thermal shock behavior
- For standard version with potting box "O":
Self-extinguishing potting and cover material - Maximum safety and durability
- High dielectric strength compared to core
- 100 % routine testing
- RoHS/REACH compliant
Further certifications/approvals on request!
max. 5.9 A
EI42
Mains chokes (passive PFC)Inductance 1.0 - 20.0 mH
Rated current: max. 5.9 A
Request product Download product information- Excellent thermal shock behavior
- For standard version with potting box "O":
Self-extinguishing potting and cover material - Maximum safety and durability
- High dielectric strength compared to core
- 100 % routine testing
- RoHS/REACH compliant
Further certifications/approvals on request!
max. 7.7 A
EI54
Mains chokes (passive PFC)Inductance 1.0 - 20.0 mH
Rated current: max. 7.7 A
Request product Download product information- Excellent thermal shock behavior
- maximum safety and durability
- High dielectric strength compared to core
- 100 % routine testing
- RoHS/REACH compliant
Further certifications/approvals on request!
max. 8.7 A
EI48
Mains chokes (passive PFC)Inductance 1.0 - 20.0 mH
Rated current: max. 8.7 A
Request product Download product information- Excellent thermal shock behavior
- For standard version with potting box "O":
Self-extinguishing potting and cover material - Maximum safety and durability
- High dielectric strength compared to core
- 100 % routine testing
- RoHS/REACH compliant
Further certifications/approvals on request!
Mains choke series (active)
Inductance range 50 µH to 1,000 µH
The "Active PFC choke series" is used in the DCM (Discontinuous Conduction Mode) and CCM (Continuous Conduction Mode) circuit topologies and meets all the requirements of renowned manufacturers of power regulators.
The inductance range is divided into application-oriented intermediate steps from 50 µH to 1,000 µH. Current values of up to 16.5 A are achieved at a frequency response of 500 kHz. By using high-quality enameled copper wire, the active PFC choke series achieves a very high impulse withstand voltage in the input range, so that intermediate circuit voltages of up to 600 V / DC are easily possible. The dielectric strength between the auxiliary and power windings is 2,000 volts or 2,500 volts from windings to core.
max. 5.5 A
PQ20
Inductance: 50 μH - 1,000 μH
Rated current: 1.5 A - 5.5 A
Request product Download product information- Excellent thermal shock behavior
- maximum safety and durability
- high dielectric strength compared to power/sense/core
- High impulse withstand voltage
- 100 % routine testing
- CE/UKCA compliant
- RoHS/REACH compliant
Further certifications/approvals on request!
max. 10 A
PQ26
Inductance: 50 μH - 1,000 μH
Rated current: 2.3 A - 10.0 A
Request product Download product information- Excellent thermal shock behavior
- maximum safety and durability
- high dielectric strength compared to power/sense/core
- High impulse withstand voltage
- 100 % routine testing
- CE/UKCA compliant
- RoHS/REACH compliant
Further certifications/approvals on request!
max. 12.5 A
PQ32
Inductance: 50 μH - 1,000 μH
Rated current: 2.9 A - 12.5 A
Request product Download product information- Excellent thermal shock behavior
- maximum safety and durability
- high dielectric strength compared to power/sense/core
- High impulse withstand voltage
- 100 % routine testing
- CE/UKCA compliant
- RoHS/REACH compliant
Further certifications/approvals on request!
max. 13.65 A
PQ32
Inductance: 50 μH - 1,000 μH
Rated current: 2.7 A - 13.65 A
Request product Download product information- Excellent thermal shock behavior
- maximum safety and durability
- high dielectric strength compared to power/sense/core
- High impulse withstand voltage
- 100 % routine testing
- CE/UKCA compliant
- RoHS/REACH compliant
Further certifications/approvals on request!
max. 16.50 A
PQ35
Inductance: 50 μH - 1,000 μH
Rated current: 4.2 A - 16.50 A
Request product Download product information- Excellent thermal shock behavior
- maximum safety and durability
- high dielectric strength compared to power/sense/core
- High impulse withstand voltage
- 100 % routine testing
- CE/UKCA compliant
- RoHS/REACH compliant
Further certifications/approvals on request!
Useful for all developers and EMC designers!
Use the service of our design kit of the product family BVD EI xxx xxxx and BVD PQ xxx xxxx.
This design kit contains the most popular passive PFC chokes from HAHN including detailed data sheets and characteristic curves (USB stick included!).
Furthermore, you can expand this kit individually from the two well-known HAHN choke series, the passive and active PFC series, or an individual design.
